SSUVPC inks are specially developed to perform on polycarbonates and vinyls. These inks have good flexibility, opacity and adhesion which is ideally suited to print panels, roll to roll labels etc.
Substrates: Poly carbonate, Vinyl, Sun board, Leather, Raincoat, Paper and Board.
Application:
- Panels
- Labels
- Stickers
Color Shades Product Code S/S UV PC PROCESS CYAN (PC) CMC 43799 S/S UV PC PROCESS YELLOW(PC) CMC 43800 S/S UV PC PROCESS MAGENTA (PC) CMC 43801 S/S UV PC PROCESS BLACK CMC 43802 S/S UV PC PAN. YELLOW C CMC 43814 S/S UV PC PAN. 012 YELLOW C CMC 43815 S/S UV PC PAN. 021 C ORANGE CMC 43816 S/S UV PC PAN. WARM RED C CMC 43817 S/S UV PC PAN. 032 C RED CMC 43818 S/S UV PC PAN. RUBINE RED C CMC 43819 S/S UV PC PAN. RHODAMINE RED C CMC 43820 S/S UV PC PAN. PURPLE C CMC 43821 S/S UV PC PAN. VIOLET C CMC 43822 S/S UV PC PAN. 072 C BLUE CMC 43823 S/S UV PC PAN. REFLEX BLUE C CMC 43824 S/S UV PC PAN. PROCESS BLUE C CMC 43825 S/S UV PC PAN. GREEN C CMC 43826 S/S UV PC PAN. BLACK C CMC 43827 S/S UV PC WHITE CMC 43828 S/S UV PC ABRASIVE(PC) CMC 43979 S/S UV WINDOW GLOSS CMC 41760 S/S UV LAMINATE MATT CMC 42442 Technical Specifications
Screen : The recommended mesh is 140 to 165 Polyester.
Conveyor Speed : 20 – 30 Meters /min
Lamps : 1
Lamp Int : 300 watt/inch
Light Fastness : 4-5 (wool scale) extra light fast inks available on request.
Squeegee : Recommended with this ink : single, double or triple durometer polyurethane blades with hardness between 85 and 75 shores.
Reducing Aid : CMC-41031 UV Reducing Aid (approx 5-10%)
Curing Promoter : CMC-41033 UV Photo Initiator (approx 3-5%)
Adhesion Promoter : CMC-48936 UV Adhesion Additive (approx 1-2%)
Cleaning : CMC-41315 UV Wash.
Standard and Legislation’s :
Shelf Life: 12 months from the date of manufacturing.
Storage: Store at moderate temperatures in a dry, well ventilated area and away from direct sunlight.
Pre-cautions : Use of gloves and eye wear is recommended.
Important Note : Strictly for over printing only. Cannot be overprinted.
Additional information : The information provided is based on extensive laboratory testing. Cure speeds depends on condition of UV lamps, reflectors, opacity and film thickness. We recommend that you pretest any ink prior to beginning a production run.
Standard and Legislations: For full details about our inks’ conformity with current standards, please refer to the document ECO SYSTEM LABEL by COLORS
Material safety data sheet available at : info@colorsuv.comCOLORS guarantee the quality of our products. We cannot however guarantee the finished results because we exercise no control over an individual operating procedures. Our responsibility is limited solely to the exchange of ink or varnish. The quality of a substrate to be printed can vary, as can an ink being overprinted; therefore the above information is given in good faith based on the state of our art and prior experience. This statement also applies to our technical assistance. When using our inks and varnishes on a new substrate or when changing operating procedures, we strongly recommend testing before use in a production situation to ensure full compatibility. Please refer to our General Conditions of Sales.
