SSUVML
-
SSUVML
SSUVML inks are glossy Inks specially developed to be used for non absorbent substraces.
Substrates: Uncoated, Handmade paper and boards
Application:
- Wedding Cards
- Letter heads
- Visiting Cards
- Garment Tags
Color Shades Product Code S/S UV YELLOW CMC-47778 S/S UV ORANGE CMC 47783 S/S UV RED CMC 47781 S/S UV DEEP RED CMC 47782 S/S UV MAROON CMC 47777 S/S UV BROWN CMC 47779 S/S UV MAGENTA CMC 47775 S/S UV PINK CMC 47776 S/S UV PEACOCK BLUE CMC 47774 S/S UV CYAN CMC 47771 S/S UV BLUE CMC 47772 S/S UV ROYAL BLUE CMC 47773 S/S UV VIOLET CMC 47784 S/S UV PURPLE CMC 47785 S/S UV GREEN CMC 47786 S/S UV VIVID GREEN CMC 47787 S/S UV OLIVE GREEN CMC 47788 S/S UV BLACK CMC 43855 S/S UV 47780 CMC 48146 S/S UV VARNISH CMC 47790 S/S UV OPAQUE WHITE CMC 47789 Technical Specifications
Screen : The recommended mesh is 77 / 100.
Conveyor Speed : 20 – 30 Meters /min
Lamps : 1
Lamp Int : 300 watt/inch
Light Fastness : 4-5 (wool scale) extra light fast inks available on request.
Squeegee : Recommended with this ink : single, double or triple durometer polyurethane blades with hardness between 85 and 75 shores.
Reducing Aid : CMC-41031 UV Reducing Aid (approx 5-10%)
Curing Promoter : CMC-41033 UV Photo Initiator (approx 3-5%)
Adhesion Promoter : CMC-48936 UV Adhesion Additive (approx 1-2%)
Cleaning : CMC-41315 UV Wash.
Standard and Legislation’s :
Shelf Life: 12 months from the date of manufacturing.
Storage: Store at moderate temperatures in a dry, well ventilated area and away from direct sunlight.
Pre-cautions : Use of gloves and eye wear is recommended.
Important Note : Strictly for over printing only. Cannot be overprinted.
Additional information : The information provided is based on extensive laboratory testing. Cure speeds depends on condition of UV lamps, reflectors, opacity and film thickness. We recommend that you pretest any ink prior to beginning a production run.
Standard and Legislations: For full details about our inks’ conformity with current standards, please refer to the document ECO SYSTEM LABEL by COLORS
Material safety data sheet available at : info@colorsuv.comCOLORS guarantee the quality of our products. We cannot however guarantee the finished results because we exercise no control over an individual operating procedures. Our responsibility is limited solely to the exchange of ink or varnish. The quality of a substrate to be printed can vary, as can an ink being overprinted; therefore the above information is given in good faith based on the state of our art and prior experience. This statement also applies to our technical assistance. When using our inks and varnishes on a new substrate or when changing operating procedures, we strongly recommend testing before use in a production situation to ensure full compatibility. Please refer to our General Conditions of Sales.
